Features to Compact Structure Diesel Concrete Pump For Concrete Conveying 12 Months Warranty
1. Streamlined appearance design, novel and beautiful, reasonable layout, compact structure and greatly enhanced hood rigidity.
2. The oil pump and valve group use world famous brands to ensure high reliability of the towing pump.
3. The use of well-known brand motors, reliability can be guaranteed, maintenance-free for life.
4. Diesel engine adopts high-end brand, with reliable performance and strong power.
5.S tube is made of high-alloy steel as a whole. The arc hopper is optimized for three-dimensional design with large volume and no accumulation of materials.
6. The inner surface of the cylinder is chrome plated 0.25-0.28mm, which greatly improves the wear resistance.
7. The main cylinder with large bore and long stroke is used to ensure the highest construction distance.
8. The use of double pump and double circuit open hydraulic system makes the system simple, the component life is extended, the reliability is higher, and it is easy to judge and eliminate the fault.
9. Wear parts such as spectacle plate and cutting ring have long service life after continuous technical research.
10. Fully consider the ease of maintenance and optimize the design. For example, the S-tube does not need to be disassembled. The S-tube uses a long and short chrome-plated sleeve.
11. The design of the key force components such as the hopper and the S-valve, using the SEAS calculation program to carry out the finite element calculation of the subdivided network of its stress state, structural stiffness, and stress concentration. With good processability, it avoids the deformation of the hopper and the S-valve broken shaft phenomenon during high-level transportation of similar products.
More Details of Compact Structure Diesel Concrete Pump For Concrete Conveying 12 Months Warranty
|
| 1. Hydraulic system
Double open hydraulic loops with 2 pumps.The reliability of the whole system is also much higher as well as the components' life is prolonged greatly. This is convenient for judgeing and removing trouble.
|
| 2. Electric control system
Compared with domestic product, the electric control system is simplest, the element quantity is fewest and its reliability is the highest.
Adopting proximity switch in hydraulic cylinder can realize changing direction with non-touch, which ensures that the direction can be changed reliably. |
|
|
| 3. Diesel Engine The pump adopt Weichai diesel engine, a first-class brand in China. It can ensure the power supply of the concrete mixer pump. |
| 4. Cooling system
The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.
|
|
